Table Size (mm)

9” x 49 “‘

10” x 50 “‘

10” x 54”

12” x 54”

Longitudinal Travel (mm)

800

900

900

900

Cross Travel (mm)

305

400

400

400

Vertical Travel (mm)

315

400

400

400

Table (No of T-slots, width x Pitch) mm

3 x 16 x 63

3 x 16 x 63

3 x 16 x 63

3 x 16 x 63

Spindle Motor HP

3

3

3

3

Spindle speed Range

16 steps 80-5440

16 steps 50-4600

16 steps 70 - 4600

16 steps 50-4600

Spindle Taper

  R8

  R8/ISO 30

ISO 30/ISO 40

ISO 30/ISO 40

Spindle Nose to Table Top (mm)

60 - 315

40 – 446

 40 - 446

 40 - 446

Spindle Centre to Column surface (mm)

270 - 520

200 – 680

200 - 680

200 - 680

Quill Travel (mm)

110

127

127

127

Quill Dia. (mm)

86

86

86

86

Auto Quill Feed (per revolution) (mm)

0.40/0.08/0.15

0.40/0.08/0.15

0.40/0.08/0.15

0.40/0.08/0.15

Ram Travel (mm)

310

480

480

480

Net Weight (kg)

1000

1300

1300

1300
